Printers
A 1.9m space supports roll and rigid media printing with white ink for enhanced artwork. VSDT technology ensures 5pl–40pl drop precision, while auto print-head maintenance and media height setting simplify operation. With 2400dpi resolution and continuous printing, it delivers quality and efficiency.
| Model | X180 Series |
| Print Head | Drop On Demand Piezoelectric Head |
| No. of Print Heads | 2-3 pcs heads for Epson i3200 / 2-3 Ricoh GEN5 |
| Productivity Modes | Express: 24 sqm/h | 35 sqm/h; Production: 16 sqm/h | 25 sqm/h; Quality: 12 sqm/h | 15 sqm/h; Fine Art: 10 sqm/h |
| Resolution | 2400dpi Max. |
| Software | Standard (SAI Photoprint); Onyx, Caldera, Wasatch (optional) |
| Media Width | Maximum 1820mm |
| Roll & Rigid Specs | Roll: Max. dimension 210mm, 40KG; Rigid: 35Kg/sqm |
| Print Width | 1800mm |
| Feeding & Taking-up System | Auto-Feeding & taking-up system; Front and Back Extension Table |
| Ink Type | Eco Solvent / UV Curable |
| Ink Supply System | 1.5L Large Bulk System with automatic supply system |
| Colors | Standard CMYK; Lc Lm/white ink option |
| Computer Configuration | Windows 7 / i7 / 8G / 1 TB / USB3.0 |
| Ink Curing System | Dual LED UV Curing System; Extended infrared heating and cooling system for Eco-Solvent Printing |
| Dimensions & Weight | Machine (LWH): 3260 × 930 × 1650mm; Main Body: 3300 × 950 × 1600mm; 1000Kg |
| Connectivity | Hi-Speed USB 3.0 |
| Power | Single Phase, 220VAC ±10%, 50/60Hz, 5500W (Machine) |
| Environment | Temperature: 15~32°C; Humidity: 40~65% RH |
| Weight | Net Weight 450kg |
